Micro 0.22um Sterile Nylon Syringe Filter for Sample Preparation

Mar. 11th, 2020
0.22um Nylon Syringe Filter is most commonly used in HPLC and other analytical applications for water or organic separation. The filter does not contain any adhesives, cleaners or surfactants, so the extract content is low and ideal for research applications. The maximum operating temperature is 50 degrees C (122 degrees F).
0.22um Nylon Syringe Filter membrane has excellent flow rate characteristics, hydrophilic properties, very low extractable level, high protein binding force, high dirt load capacity and mechanical stability.
In general, 0.22um Nylon Syringe Filter are an excellent "main" membrane selection when acidic samples are not filtered.
Adding 0.22um Nylon Syringe Filter steps prior to chromatography not only helps ensure more consistent and reliable results, but also helps protect precision instruments and extend column life.

Filter Media

Nylon /PTFE /PES /PTFEL/ PVDF/ PVDF L

Pore Size, μm

0.22μm, 0.45μm

Diameter

13mm

25mm

Housing

PP

PP

Filtration Area

1.0cm2

4.3cm2

Maximum Operating Pressure

6.2bar

6.2bar

Process Volume

10ml

100ml

Hold-up Volume

< 25μl

<100μl

Inlet

Female Luer Lock

Female Luer Lock

Outlet

Male Luer Unlock

Male Luer Unlock

Flow Direction

Flow should enter from the inlet

Maximum Operating Temperature

267.8F

Sterilization

Autoclave at 249.8F at 1 bar for 20 minutes/EO/Gamma

Aijiren is the leading supplier of lab consumables,if there have any requirement about 0.22um Nylon Syringe Filter,please contact with us right NOW !
